Connecting Energy with Precision
Product Features
- High-Efficiency Energy Transfer Design: Utilizes a direct-pressurized welding structure that enables ultrasonic energy to be effectively transmitted to the welding interface, enhancing energy utilization efficiency and achieving stable, high-quality metal bonding.
- Low Heat-Input Process: Through precise amplitude control and low-energy vibration technology, heat accumulation and metal spatter during the welding process are effectively reduced, minimizing thermal damage to workpieces, coatings, and sensitive components.
- High-Precision Displacement Monitoring: Equipped with a high-resolution displacement sensing system to monitor weld height, compression depth, and displacement changes in real time, ensuring high consistency and precision for every weld.
- Full Closed-Loop Digital Control Platform: The T-sonic full closed-loop control system integrates multiple process parameters—including amplitude, energy, time, pressure, and displacement—offering versatile welding modes to meet the demands of different materials and diverse applications.
- Intelligent Process Data Management: The system captures key process data in real time, including Energy, Power, Amplitude, Distance, and Welding Time. All data serves as a basis for quality traceability and process analysis, while supporting smart manufacturing and MES system integration.
- Dynamic Pressure Control Technology: Through real-time dynamic pressure adjustment and trigger mechanisms, the system precisely controls the weld trigger point and pressure variations during the welding process, enhancing welding stability and joint quality consistency.
Add to inquiry cart
Specification
Welding applications
| Overall Dimensions (L x W x H) (mm) | 650 x 315 x 915 Frame Weight Approx. 140kg |
| Operating Voltage | 220V AC (4kW) |
| Operating Air Pressure | 0.5-0.6MPa |
| Cylinder Diameter | φ125mm |
| Stroke | 50mm |
| Operating Temperature | +5°C-50°C |
| Operating Humidity | 30%~95% |
| Available Stroke | 10mm~45mm |
| Allowable Pressure Range | 0.05MPa~0.5MPa |
| Descending Speed | 8mm/s~99mm/s |
| Generated Force Range | 500N~6000N |
Ultrasonic metal welding is a solid-state joining technology. During welding, high-frequency ultrasonic vibrations are transmitted to the metal workpieces via the welding horn. Under a specific pressure, this induces high-frequency micro-slip and localized plastic deformation at the joining interface, breaking down surface oxide layers and contaminants to form a metallurgical bond between metal atoms. Since the entire joining process does not require melting the base materials, it effectively minimizes the heat-affected zone, preserves the original properties of the materials, and achieves high-strength, low-resistance, and highly consistent joint quality.
- Battery Modules & Current Collectors
- Power & Energy Storage Batteries
- Wire Terminals & Harness Assemblies
- Motors, Relays & Contactors
- Electromagnetic Coils & Transformers
- Capacitors & Sensing Components
- Heat Sinks & Cooling Plates
- Solar Modules
- Airbag Initiators
- Switches & Power Electronic Components
